House Plan HPR-1613

Total Living Area: 1718 Sq. Ft.
Main Level: 1718 Sq. Ft.
Lower Floor: 482 Sq. Ft.
Bonus: 85 Sq. Ft.
Bedrooms: 3
Full Baths: 2, Half Baths: 1
Width: 54 Ft.    Depth: 34 Ft.
Garage Size: 3
Foundation: WALK OUT BASEMENT
3D Tour

Plan Packages

HOUSE PLAN SETS
 PDF BID SET  $625.00
 PDF File  $975.00
 Vellums  $975.00
 Five Sets of Plans  $1,100.00
FOUNDATION OPTIONS
 WALK OUT BASEMENT  $0.00
ADDITIONAL PLAN OPTIONS
 Mirror Reverse  $50.00
 Materials List  $60.00
 Right Read Reverse  $250.00
 New Foundation Type  $300.00
 Conversion to 2 x 6 Walls  $200.00

For more details about our plan packages click here

Photographs, if shown, may reflect homeowner modifications. © Copyright by designer.

Need to make changes?
Request a free online quote.
Create an online portfolio of
favorite house plans.
Each week receive our
free e-newsletters.

© copyright by designer
Floor Plan:
Floor Plan image of SYCAMORE-A House Plan
© copyright by designer
Lower Level:
Lower Level image of SYCAMORE-A House Plan
Plan Specifications
  GENERAL HOUSE INFORMATION
Number of Stories:1.5
Width:54' 0"
Depth:34' 0"
Dwelling Number:Single
Bonus Access:None
  EXTERIOR STYLE
Traditional
European
PDFs Fast!
  NUMBERS OF ROOMS
Bedrooms:3
Full Baths:2
Half Baths:1
  FINISHED SQUARE FOOTAGE
Main Level:1718 Sq. Ft.
Lower Level:482 Sq. Ft.
Total: 1718 Sq. Ft.
  UNFINISHED SQUARE FOOTAGE
Garage:928 Sq. Ft.
Deck:172 Sq. Ft.
Bonus Room:85 Sq. Ft.
  GARAGE
Garage Type:
Garage Size:3
  FOUNDATION
WALK OUT BASEMENT
  HOUSE AND CEILING HEIGHTS
First Floor Ceiling:8
Maximum House Height:27' 0"
  FRAMING INFORMATION
Roof Framing:Stick
Exterior Wall Framing:2x4
  ROOF PITCH
Primary:9/12
Gable:9/12
  ROOF LOAD
Live:20
Dead:10
  INSULATION (R)
Per IRC Climate Zones
  KEY FEATURES
2 Story Volume
Arches
Attached
Country Kitchen
Deck
Dining Room
Double Vanity Sink
Drive-under
Fireplace
Foyer
Great Room
Laundry 2nd Fl
  KEY FEATURES
Master Bdrm Main Floor
Nook / Breakfast Area
Open Floor Plan
Separate Tub and Shower
Side-entry
Split Bedrooms
Suited for corner lot
Suited for sloping lot
Unfinished Space
Vaulted Ceilings
Walk-in Closet
Walkout Basement
